DATASHEET - IP40 Class II Power Supply

www.lumeno.ie
ps12v35pc-1
ps12v35pc-1ps12v35pc-2
LM-PS12V35PC

12V 35W, Power Supply, n/d, plastic, terminals

No vote
  • Single channel constant voltage output
  • Plastic housing and class II design without FG
  • Universal AC input / Full range
  • 100% full load burn-in test
  • No load power consumption<0.5W
  • High efficiency, long life and high reliability

Compact, plastic case power supply with 5mm terminal blocks.

Technical Specification

ModelLM-PS12V35PC
Standby Power 0.5W
Input Voltage (Pri) 110V - 240V AC
Output (Vo) 12V DC
Output Power (P) 35 Watt
Current Output (Io) 2.92A
Power Factor 0.95
Ingress Protection IP20
Dimming non-dimmable
Size 145*33.5*22mm
Weight 75g
Warranty Period 1 Year
Working Temperature -20°C~+60°C, 20%~90%RH
Protection Over Load, Over Voltage, Over Temperature
Certification CE ROHS Certified
